“How many rods in 16mm bundle?”, generally there are 3 pieces of rods or Steel bar available in 16 mm bundle but their actual figure depends on their manufacturer and Steel Company. It can be available in full length of 12 meter (40 feet) or U shaped bent and sold per pieces, in kg, quintal and tons.

How do you work out the weight of a 16mm bar?

Ans. 1.58 Kgs is weight of 16mm Steel rod per metre. If dia of steel = 16mm, length of 1 steel rod = 12 meter, then weight of 1 piece of 16mm steel rod in kg = (16×16×12)/162 = 18.96 kgs, so weight of 1 piece 16mm Steel rod is 18.96 kgs.

How do I know what weight my rod is?

To calculate the weight of steel bars:

ROUND – dia. mm2 x 0.006165 = Weight in kilograms per metre. ROUND – dia. mm2 x 0.004143 = Weight in lbs.

How many pieces of 12mm rod makes a ton?

Mathematical calculation such as number of pieces of 12mm Rods in one ton = 1000kg/weight of one piece of 12mm Rod, 1000kg ÷ 10.667kg = 94 pieces. Therefore 94 No’s of 12 meter of 12mm Rod or steel bar makes a ton.

How many rods make a ton?

Standard length of Iron rods in the market

That in imperial unit is approximately 39 ft 4 inches. For example, a ton of y16 reinforcement bar contains 52 pieces of 12 meter length steel bars in total.

How do you calculate 162 steel?

Calculation Of The Formula D²L/162:

The weight of steel bars= Cross sectional area of steel bar x Length of steel bar x Density of steel bar.

How do you calculate the weight of a steel rod in kg?

Multiply the total length of bar with the following unit weight. For, 10mm ø bar = 0.617 kg/m. 12mm ø bar = 0.888 kg/m.

10mm ø bar = 0.188 kg/ft.12mm ø bar = 0.270 kg/ft.16mm ø bar = 0.480 kg/ft.20mm ø bar = 0.750 kg/ft.25mm ø bar = 1.172 kg/ft.

How do you calculate the weight of a 10mm rod?

Hence, the weight of :

10mm dia bar = (10x10x1)/162.28 = 0.616kg.
