The electrical code allows outlets to be installed with the ground plug hole facing up, down or sideways. It’s up to you, there is no standard electric outlet orientation. So that means there really is no such thing as upside down outlets.

Why are outlets installed upside down?

Electricians may position the outlet in an upside-down position so that you can quickly identify the switch-controlled receptacle. Since it stands out visually to most people right away – it provides convenience to the occupants to easily remember which outlet is switch controlled.

Does the ground go on top or bottom?

With the ground in the upper position, the ground prong on the plug could pull out with the hot and neutral still energized, thus creating a possible electrocution hazard. Ground should be at bottom that way if the plug is accidentally pulled; the last prong to disconnect will be the ground.

Is it code to install outlets upside down?

The electrical code allows outlets to be installed with the ground plug hole facing up, down or sideways. It’s up to you, there is no standard electric outlet orientation. So that means there really is no such thing as upside down outlets.

Should outlets be vertical or horizontal?

For electrical receptacles installed in walls, the NEC does not specify orientation, either vertical or horizontal, and if vertical it does not specify ground pin down or ground pin up. By far the most common mounting arrangement in the US for such receptacles mounted in walls is vertical, ground pin down.

Where should electrical outlets be placed?

It would be best to place plenty of electric outlets in every corner of your sitting room. Place additional outlets in the middle of each wall. If you want to hang a TV on the wall, place an outlet behind the screen to avoid hanging messy cords.

Can a receptacle be mounted face up?

Receptacles, unless listed as receptacle assemblies for countertop applications, shall not be installed in a face-up position in countertops or similar work surfaces.

Does a receptacle need to be grounded?

since 1962, U.S. electrical code has required all outlets to have a ground. When an error or surge occurs with grounding, the energy travels through the ground wire to the electrical panel. There, it will trip the circuit breaker or blow a fuse, thereby shutting down the circuit before damage (hopefully) occurs.

Why do plugs have 2 holes on the end?

Rather than having deliberate gaps in the middle of the metal, the design used to feature semi-circular indents on either side of the plug. These indents were designed to hook the plug to the socket and prevent it from falling out.

Can you mount outlets horizontal?

Yes, you can mount an ordinary wall-type receptacle outlet horizontally with the face up, with two exceptions: 1) Receptacles on a countertop or work surface must be specially rated for that use, per NEC 405.6(B), and are typically pop-up type.

Can I install outlet sideways?

Electrical receptacles can be mounted sideways wherever space is an issue. Turn off the power at the service panel. Check the wires with the circuit tester to be sure the power is off. Orient the receptacle box horizontally against the wall in the desired spot.

How far should an outlet be from a corner?

The National Electrical Code requires that you have an electrical outlet within 6 feet of the corner of the wall and at least 12 feet from the same wall.
