What does a thermocouple do on a gas furnace?

Thermocouples are sensors used to measure temperature. It is a device used inside a gas furnace in Kansas, to assist the pilot light in keeping your furnace running and safe. It works rather like a fail-safe to keep unburned gas from accumulating and burning, exploding or causing another type of health risk.

How much does it cost to replace a furnace thermocouple?

Thermocouple. If your furnace is an older model with a pilot light, it relies on a thermocouple to shut off its gas valve if the flame goes out. The average cost to repair or replace a thermocouple is $100–$250.

How do I know if my thermocouple is bad on my furnace?

A bad thermocouple itself can prevent a gas furnace or boiler from working – if you can light the flame at the pilot manually but then the flame goes out when you release the manual gas feed valve, the thermocouple is probably bad.

How much is a thermocouple for a gas furnace?

It costs $150 to $250 to replace a thermocouple. It checks to make sure the pilot light is on. It will shut the gas off if it’s not.

What causes a thermocouple to fail?

A good thermocouple is going to be used, and that can lead to metal fatigue. Changes in temperature can cause regular expansion and contraction in metal, which will cause thermocouples to weaken over time. After enough time, metal fatigue can cause a thermocouple to break.

How long do furnace thermocouples last?

Thermocouples can last up to 10 years if properly installed and maintained, while furnaces can last 15-20 years, although either may wear out sooner in multifamily units.

Can I replace a thermocouple myself?

The No. 1 cause of pilot lights that won’t stay lit is a worn-out thermocouple. It’s easy to replace and a new one costs $5 to $10. Rather than trying to unfasten the thermocouple inside the water heater’s burning chamber, it’s easier to remove the whole burner and thermocouple assembly.

Why is my pilot light not staying lit on my furnace?

If your pilot light won’t stay alight, it might be the thermocouple. Sometimes dust buildup collects on the thermocouple and blocks the sensor. Try cleaning the thermocouple and then relighting the pilot light. If it continues to go out, the thermocouple might need to be replaced.

Why does my furnace flame keep going out?

Your furnace has a limit switch that keeps it from running if the heat exchanger is too hot. Dirty filters, closed or blocked vents and other blockages in airflow are common causes of an overheated furnace. A bad limit switch. The limit switch may be bad and need to be replaced.

What happens when thermocouple goes bad?

Normally when the thermocouple malfunctions or isn’t working, it simply shuts off the gas to your heater. This is important, particularly if the pilot light is out, because it prevents harmful gas from leaking into your home.

Will a pilot light stay lit with a bad thermocouple?

A thermocouple senses the heat of the pilot and allows gas to flow to the burner. A bad thermocouple will shut off gas to both the pilot and the burner so the pilot light won’t stay lit.

Can you clean a thermocouple?

Yes, you can clean a thermocouple, but the task must be done with a light touch. Remove the thermocouple from the process assembly, using a steel wool or emery cloth, lightly clean the tip removing any build up.

Should thermocouple be in pilot flame?

The pilot flame should touch the thermocouple at a specific level. If the flame is blue and weak, and barely reaches the thermocouple, it needs to be stronger. If it extends well above the thermocouple, it’s too strong.

Can you bypass thermocouple on furnace?

Realistically, you have just disabled the thermocouple, but you can also reach in and unclip it from its holding bracket where it meets the pilot light. In most cases it will be held on with a gravity clip, but some are held on with a screw that must be removed with a small screwdriver.

Do all gas furnaces have thermocouples?

Most gas furnaces use either a flame sensor or a thermocouple, sometimes referred to as a “thermal coupler.” Both are safety devices that sense the presence of a flame and control the flow of gas to the appliance accordingly.

How do I know if I need a new thermocouple?

A working thermocouple will give a reading of between 25 and 30 millimeters. If the reading is less than 25 millimeters, it should be replaced.

What is the most common thermocouple failure mode?

The most common failure mode for thermocouples is for them to fail open, this is known as thermocouple burnout. Burnout can result from a variety of reasons including the thermocouple experiencing a temperature in excess of that for which it was designed, metal fatigue, and oxidation.
