Suspect Parameter Number (SPN) Represents the SPN with error. Every defined SPN can be used in a DTC. Failure Mode Identifier (FMI) Represents the nature and type of error that occurred, e.g., value range violation (high or low), sensor short-circuits, incorrect update rate, calibration error.

What is an SPN code?

Military Separation Program Numbers (SPN Codes) define the reason a discharge or separation was granted. SPN Codes were replaced by alpha-numeric separation codes but can still be found on many older DD-214s.

What does FMI 0 mean?

Description. 0. High – most severe (3)

What is an FMI 2 code?

2 = Data Erratic, Intermittent or Incorrect (rationality) 3 = Voltage Above Normal, or Shorted to High Source. 4 = Voltage Below Normal, or Shorted to High Source.

What does FMI 31 mean?

SPN 521049/FMI 31

Description This Code Sets When There is a Code Present for the Diesel Exhaust Fluid (DEF) Tank Level, DEF Dosing Unit, DEF Pump, NOx Sensors, Blocked DEF Line, DEF Quality, NOx Efficiency, Selective Catalyst Reduction (SCR) Harness and/or SCR Sensor.

What is SPN and FMI in J1939?

The FMI is used along with the SPN to provide specific information that relates to a diagnostic trouble code (DTC). The FMI may indicate that a problem with an electronic circuit or an electronic component has been detected. The codes are displayed in the form “SPN – FMI”.

What does FMI 15 mean?

FMI 15: Data Valid but Above Normal Operating Range – Least Severe Level. Reason: The aftertreatment diesel particulate filter (DPF) requires exchange or cleaning. Effect: None on performance.

What is SPN in J1939?

The J1939 specification has defined the following term for the PGN contents: Suspect Parameter Number (SPN). An SPN is for all intents and purposes a signal ID. It can be a physical value, a status, or a command. SPNs are also defined for internal protocol information.

What numeric code is used to identify the engine controller SA?

The J1939 fault code error message consists of a Source Address (SA) identifying the Electronic Control Unit (ECU) sending the DTC (SA0 = Engine Controller #1), a Suspect Parameter Number (SPN) which identifies the parameter sending the fault code error message, and a Failure Mode Identifier (FMI) which identifies the

What is a J1939 data link?

J1939 is a high-speed vehicle data link that can communicate at either 250kb/s or 500kb/s. The datalink consists of three wires: yellow is CAN +, green is CAN – and Shield is connected to ground.

What is fault code J1708?

SAE J1708 is a standard used for serial communications between ECUs on a heavy duty vehicle and also between a computer and the vehicle. With respect to Open System Interconnection model (OSI), J1708 defines the physical layer. Common higher layer protocols that operate on top of J1708 are SAE J1587 and SAE J1922.

What does PID mean in automotive?

OBD-II PIDs (On-board diagnostics Parameter IDs) are codes used to request data from a vehicle, used as a diagnostic tool. SAE standard J1979 defines many OBD-II PIDs.

What does Sid PID mean?

PID – Process ID. PPID – Parent Process ID. SID – Session ID. PGID – Process Group ID. UID – User ID.

What is code SPN 3251?

SPN 3251/FMI 0 – EPA07

This diagnostic is typically Diesel Particulate Filter (DPF) Pressure Out of Range Very High. This fault code sets when the DPF outlet pressure is greater than 35 kPa (5 psi) for more than 10 seconds.

What does code 1569 mean?

SPN 1569 FMI 31 SA 0. This code is a warning that the engine might de-rate, and must be associated with the exclamation mark. SPN 3362 FMI 31 SA 0. This code indicates a problem with the DEF system. The DEF might be too low, bad, wrong mixture, frozen or some sensor is broken.

What does engine protection torque derate mean?

A derate means that the program inside the engine computer limits either the power or vehicle speed. A derate is designed to protect you from causing engine or DPF damage. A derate can be caused by various sensors or systems.
