The instruction ‘LXI B, 4000H’ loads the register pair BC with the contents of memory location 4000H. Τ Τ F 2. The instruction ‘CPI 14H® compares the immediate value 14H to the contents of the accumulator and sets the flags appropriately.

What is the output of LXI H 2050H?

LXI H,2050H L=50H H=20H LXI instruction takes 3 bytes of memory and 10 clock periods.

What is the size of LXI instruction?

In 8085 Instruction set, LXI SP, d16 instruction is a special case of LXI rp, d16. Using this instruction, we can load 16-bit immediate data/address on the Stack Pointer (SP). It occupies 3-Bytes in the memory.

Is 3 Byte A instruction?

Three-byte instruction is the type of instruction in which the first 8 bits indicates the opcode and the next two bytes specify the 16-bit address. The low-order address is represented in second byte and the high-order address is represented in the third byte.

What is LXI instruction?

These instructions are used to load the 16-bit address into the register pair. We can use this instruction to load data from memory location using the memory address, which is stored in the register pair rp. For an example, if the instruction is LXI H, FE50. It means that the FE50 is loaded into the HL register pair.

What is the full form of LXI in microprocessor?

The LXI (LAN eXtensions for Instrumentation) Consortium defines standard ways for Ethernet-based instruments to communicate, operate and function.

What is 8085 instruction set?

 The entire group of instructions that a microprocessor supports is called Instruction Set.  8085 has 246 instructions.  Each instruction is represented by an 8-bit binary value.  These 8-bits of binary value is called Op-Code or Instruction Byte.

What addressing mode is used in the instruction LXI B 0345H?

239)What addressing mode is used in the instruction LXI B 0345H? Immediate.

What is LHLD instruction?

In 8085 Instruction set LHLD is a mnemonic that stands for Load HL pair using Direct addressing from memory location whose 16-bit address is denoted as a16. This instruction uses absolute addressing mode for specifying the data in the instruction. It occupies 3-Bytes in the memory.

How many instructions are there in 8085?

– The 8085 uses a total of 246 bit patterns to form its instruction set. – These 246 patterns represent only 74 instructions.

How are instructions classified?

These instructions can be classified into the following five functional categories: data transfer (copy) operations, arithmetic operations, logical operations, branching operations, and machine-control operations. An instruction is a binary pattern designed inside a microprocessor to perform a specific function.

Which of the following is not correct about HLT instruction?

Which of the following is not correct about HLT instruction? Explanation: HLT is a machine control statement. Internally, the PC is disconnected from the address bus so, the next fetch is not possible. It is used mainly to stop the execution of the program.

Which of the following is 1-byte instruction?

INR is a 1-byte instruction as it requires 1-Byte, 3-Machine Cycles (Opcode Fetch, Memory Read, Memory Write) and 10 T-States.

How many bytes instruction HLT has?

In 8085 Instruction set, HLT is the mnemonic which stands for ‘Halt the microprocessor’ instruction. It is having a size of 1-Byte instruction. Using these particular instructions, as 8085 enters into the halt state, so we can put the8085 from further processing of next instructions.

What is LDA instruction?

In 8085 Instruction set, LDA is a mnemonic that stands for LoaD Accumulator with the contents from memory. In this instructionAccumulatorwill get initialized with 8-bit content from the 16-bit memory address as indicated in the instruction as a16.

What is RRC instruction?

In 8085 Instruction set, RRC stands for “Rotate Right Accumulator”. With the help of this instruction, we can rotate the Accumulator current content to the right by 1-bit position.

What does DAA instruction do in 8085?

Detailed Solution. DAA means decimal adjust accumulator and it is used in BCD addition. DAA instruction changes the binary values of contents of the accumulator to BCD.
